The LiMAR W&B Optical Fibre Rope Socket is designed to terminate and connect the end of the specialised W&B SlickLight-S to a toolstring.
A unique Pear Drop and Sleeve arrangement can be assembled rapidly to provide and maintain a reliable grip to the wire whilst simultaneously terminating the optical fibre line.
TOOL APPLICATIONS:
- For use with W&B SlickLight-S to enable a reliable attachment to the toolstring
DESIGN FEATURES & BENEFITS:
- Rapid mechanical assembly and disassembly
- All mechanical slickline connection options available
- HDR (Hydraulic Delay Releasable) options available to provide release function
- Simple, robust design ensuring ease of operation for the end user
- Selected components QPQ treated
- Hexagonal flats for safe make-up & break-out
- Sour Service versions available
TECHNICAL DATA
Assembly Part No. | Actual OD | Wire Size / Type | Connection | Make Up Length |
| 1259-1375-0159-XXX-RX | 1.375" | 4mm (0.159”) W&B SlickLight-S | Optional | 14.16” (SR) |
| 1259-1375-0181-XXX-RX | 1.375” | 4.6mm (0.181”) W&B SlickLight-S | Optional | 14.16” (SR) |
XXX - Last 3 digits of part number denotes connection type
For additional sizes or further information please contact sales
For HDR Releasable options, please contact LiMAR for more information
